Send Inquiry | Model | Overall dimension (mm) | Limit speed (RPM) | Rated load/th> | Weight | ||||
|---|---|---|---|---|---|---|---|---|---|---|
| d | D | B | Grease | Oil lubrication | Cr(N) | Cor(N) | ||||
| 51100 | 10 | 24 | 9 | 6500 | 10000 | 10 | 14 | 0.02 | ||
| 51101 | 12 | 26 | 9 | 6500 | 10000 | 10.3 | 15.4 | 0.022 | ||
| 51102 | 15 | 28 | 9 | 6100 | 9400 | 10.5 | 16.8 | 0.024 | ||
| 51103 | 17 | 30 | 9 | 6100 | 9400 | 10.8 | 18.2 | 0.028 | ||
| 51104 | 20 | 35 | 10 | 5100 | 7900 | 14.2 | 24.7 | 0.04 | ||
| 51105 | 25 | 42 | 11 | 4400 | 6800 | 19.5 | 37.2 | 0.059 | ||
| 51106 | 30 | 47 | 11 | 4300 | 6600 | 20.4 | 42.2 | 0.068 | ||
| 51115 | 75 | 100 | 19 | 2200 | 3400 | 42.3 | 127 | 0.42 | ||
| 51107 | 35 | 52 | 12 | 3900 | 6000 | 20.4 | 44.7 | 0.09 | ||
| 51116 | 80 | 105 | 19 | 2100 | 3300 | 44.6 | 141 | 0.43 | ||
| 51108 | 40 | 60 | 13 | 3400 | 5300 | 26.9 | 62.8 | 0.12 | ||
| 51117 | 85 | 110 | 19 | 2100 | 3200 | 45.9 | 150 | 0.46 | ||
| 51109 | 45 | 65 | 14 | 3200 | 5000 | 27.8 | 69.1 | 0.15 | ||
| 51118 | 90 | 120 | 22 | 1900 | 2900 | 59.7 | 190 | 0.68 | ||
| 51110 | 50 | 70 | 14 | 3100 | 4800 | 28.8 | 75.4 | 0.16 | ||
| 51120 | 100 | 135 | 25 | 1600 | 2500 | 85 | 268 | 0.99 | ||
| 511111 | 55 | 78 | 16 | — | — | — | — | 0.24 | ||
| 51122 | 110 | 145 | 25 | 1600 | 2400 | 87.1 | 288 | 1.08 | ||
| 51112 | 60 | 85 | 17 | 2600 | 4000 | 41.4 | 113 | 0.29 | ||
| 51124 | 120 | 155 | 25 | 1500 | 2300 | 89 | 308 | 1.16 | ||
