Send Inquiry | Model | Overall dimension (mm) | Limit speed (RPM) | Rated load/th> | Weight | ||||
|---|---|---|---|---|---|---|---|---|---|---|
| d | D | B | Grease | Oil lubrication | Cr(N) | Cor(N) | ||||
| FC2028104 | 100 | 140 | 104 | 3600 | 4400 | 350 | 470 | 5.2 | ||
| FC202870 | 100 | 140 | 70 | 2730 | 3270 | 300 | 400 | 3.7 | ||
| 381040X2 | 200 | 310 | 200 | — | — | 1450 | 1520 | 55.6 | ||
| 380641 | 205 | 320 | 205 | — | — | 1372 | 2850 | 55.4 | ||
| 382040 | 200 | 310 | 275 | — | — | 1558 | 4200 | 75.1 | ||
| 7603035TNl | 30 | 72 | 19 | — | — | — | — | 0.401 | ||
| 7602020TNl | 20 | 47 | 14 | — | — | — | — | 0.123 | ||
| 7603040TNl | 40 | 90 | 23 | — | — | — | — | 0.728 | ||
| 7602025TNl | 25 | 52 | 15 | — | — | — | — | 0.144 | ||
| 7603045TNl | 40 | 90 | 23 | — | — | — | — | 0.728 | ||
| 7602030TNl | 30 | 62 | 16 | — | — | — | — | 0.225 | ||
| 76035055TMl | 40 | 90 | 23 | — | — | — | — | 0.728 | ||
| 7602035TNl | 35 | 72 | 17 | — | — | — | — | 0.324 | ||
| 7603055TNl | 55 | 120 | 29 | — | — | — | — | 1.63 | ||
| 7602040TNl | 40 | 80 | 18 | — | — | — | — | 0.418 | ||
| 7602045TNl | 45 | 85 | 19 | — | — | — | — | 0.467 | ||
| 7602050TNl | 50 | 90 | 20 | — | — | — | — | 0.533 | ||
| 7603030TNl | 50 | 90 | 20 | — | — | — | — | 0.533 | ||
| 7603025TNl | 25 | 62 | 17 | — | — | — | — | 0.266 | ||
| GE100CS-2Z | 100 | 150 | 70 | - | - | - | - | - | ||
