Send Inquiry | Model | Overall dimension (mm) | Limit speed (RPM) | Rated load/th> | Weight | ||||
|---|---|---|---|---|---|---|---|---|---|---|
| d | D | B | Grease | Oil lubrication | Cr(N) | Cor(N) | ||||
| NU202 | 15 | 35 | 11 | 15000 | 19000 | 7.98 | 5.5 | — | ||
| NU205E | 25 | 52 | 15 | 11000 | 14000 | 27.5 | 26.8 | 0.14 | ||
| NU203 | 17 | 40 | 12 | 14000 | 18000 | 9.12 | 7 | — | ||
| NU2205E | 25 | 52 | 18 | 11000 | 14000 | 32.8 | 33.8 | 0.168 | ||
| NU303 | 17 | 47 | 14 | 13000 | 17000 | 12.8 | 10.8 | 0.147 | ||
| NU305E | 25 | 62 | 17 | 9000 | 12000 | 38.5 | 35.8 | 0.251 | ||
| NU1004 | 20 | 42 | 12 | 13000 | 17000 | 10.5 | 9.2 | 0.09 | ||
| NU2305E | 25 | 62 | 24 | 9000 | 12000 | 53.2 | 54.5 | 0.355 | ||
| NU204E | 20 | 47 | 14 | 12000 | 16000 | 25.8 | 24 | 0.117 | ||
| NU1006 | 30 | 55 | 13 | 9500 | 12000 | 13 | 12.8 | 0.12 | ||
| NU2204E | 20 | 47 | 18 | 12000 | 16000 | 30.8 | 30 | 0.149 | ||
| NU206E | 30 | 62 | 16 | 8500 | 11000 | 36 | 35.5 | 0.214 | ||
| NU3O4E | 20 | 52 | 15 | 11000 | 15000 | 29 | 25.5 | 0.155 | ||
| NU2206E | 30 | 62 | 20 | 8500 | 11000 | 45.5 | 48 | 0.268 | ||
| NU2304E | 20 | 52 | 21 | 10000 | 14000 | 39.2 | 37.5 | 0.216 | ||
| NU306E | 30 | 72 | 19 | 8000 | 10000 | 49.2 | 48.2 | 0.377 | ||
| NU1005 | 25 | 47 | 12 | 11000 | 15000 | 11 | 10.2 | 0.1 | ||
| NU2306E | 30 | 72 | 27 | 8000 | 10000 | 70 | 75.5 | 0.538 | ||
| NU406 | 30 | 90 | 23 | 7000 | 9000 | 57.2 | 53 | 0.73 | ||
| NU1007 | 35 | 62 | 14 | 8500 | 11000 | 19.5 | 18.8 | 0.16 | ||
