Send Inquiry | Model | Overall dimension (mm) | Limit speed (RPM) | Rated load/th> | Weight | ||||
|---|---|---|---|---|---|---|---|---|---|---|
| d | D | B | Grease | Oil lubrication | Cr(N) | Cor(N) | ||||
| 2222K+H322 | 100 | 200 | 53 | - | - | - | - | - | ||
| 1204K+H204 | 20 | 47 | 40 | 14000 | 17000 | 9.9 | 2.6 | 0.191 | ||
| 1205K+H205 | 25 | 52 | 44 | 12000 | 14000 | 12.1 | 3.3 | 0.266 | ||
| 1206K+H206 | 30 | 62 | 48 | 9900 | 12000 | 15.6 | 4.65 | 0.36 | ||
| 1207K+H207 | 35 | 72 | 52 | 8500 | 10000 | 15.8 | 5.1 | 0.556 | ||
| 1208K+H208 | 40 | 80 | 56 | 7500 | 9200 | 19.2 | 6.5 | 0.733 | ||
| 1209K+H209 | 45 | 85 | 58 | 7000 | 8500 | 21.8 | 7.35 | 0.793 | ||
| 1210K+H210 | 50 | 90 | 58 | 6500 | 7900 | 22.7 | 8.1 | 0.875 | ||
| 1211K+H211 | 55 | 100 | 60 | 5800 | 7100 | 26.8 | 10 | 1.16 | ||
| 1212K+H212 | 60 | 110 | 62 | 5200 | 6400 | 30.2 | 11.5 | 1.52 | ||
| 1203K+H203 | 17 | 47 | 14 | - | - | - | - | - | ||
| 1213K+H213 | 65 | 130 | 25 | - | - | - | - | - | ||
| 1214K+H214 | 70 | 140 | 26 | - | - | - | - | - | ||
| 1304K+H304 | 20 | 52 | 44 | 13000 | 15000 | 12.4 | 3.35 | 0.266 | ||
| 1215K+H215 | 75 | 150 | 28 | - | - | - | - | - | ||
| 1305K+H305 | 20 | 62 | 48 | 9900 | 12000 | 17.6 | 4.95 | 0.445 | ||
| 1216K+H216 | 80 | 160 | 30 | - | - | - | - | - | ||
| 1306K+H306 | 30 | 72 | 52 | 8700 | 11000 | 21.3 | 6.3 | 0.614 | ||
| 1217K+H217 | 85 | 170 | 32 | - | - | - | - | - | ||
| 1307K+H307 | 35 | 80 | 56 | 7600 | 9300 | 25.1 | 7.85 | 0.821 | ||
