Send Inquiry | Model | Overall dimension (mm) | Limit speed (RPM) | Rated load/th> | Weight | ||||
|---|---|---|---|---|---|---|---|---|---|---|
| d | D | B | Grease | Oil lubrication | Cr(N) | Cor(N) | ||||
| 7000C | 10 | 26 | 8 | 47000 | 62000 | 5.3 | 2.45 | 0.021 | ||
| 7002AC | 15 | 32 | 9 | 26000 | 32000 | 6.1 | 3.45 | 0.035 | ||
| 7000AC | 10 | 26 | 8 | 34000 | 42000 | 5 | 2.35 | 0.021 | ||
| 7202C | 15 | 35 | 11 | 33000 | 43000 | 8065 | 4.55 | 0.048 | ||
| 7200C | 10 | 30 | 9 | 40000 | 54000 | 5 | 2.35 | 0.031 | ||
| 7202AC | 15 | 35 | 11 | 24000 | 29000 | 8.1 | 4.25 | 0.048 | ||
| 7200AC | 10 | 30 | 9 | 29000 | 37000 | 4.65 | 2.2 | 0.031 | ||
| 7003C | 17 | 35 | 10 | 31000 | 41000 | 7.3 | 4.45 | 0.045 | ||
| 7001C | 12 | 28 | 8 | 40000 | 54000 | 5.8 | 2.95 | 0.024 | ||
| 7003AC | 17 | 35 | 10 | 23000 | 28000 | 6.75 | 4.15 | 0.045 | ||
| 7001AC | 12 | 28 | 8 | 29000 | 37000 | 5.4 | 2.75 | 0.024 | ||
| 7203C | 17 | 40 | 12 | 29000 | 38000 | 10.9 | 5.9 | 0.07 | ||
| 7201C | 12 | 32 | 10 | 38000 | 50000 | 7.9 | 3.85 | 0.038 | ||
| 7203AC | 17 | 40 | 12 | 21000 | 26000 | 10.2 | 5.5 | 0.07 | ||
| 7201AC | 12 | 32 | 10 | 27000 | 34000 | 7.45 | 3.65 | 0.038 | ||
| 7004C | 20 | 42 | 12 | 26000 | 35000 | 11.1 | 6.6 | 0.079 | ||
| 7002C | 15 | 32 | 9 | 35000 | 47000 | 6.6 | 3.7 | 0.035 | ||
| 7004AC | 20 | 42 | 12 | 19000 | 24000 | 10.3 | 6.1 | 0.079 | ||
| 7204C | 20 | 47 | 14 | 24000 | 32000 | 15.5 | 9 | 0.112 | ||
| 7204AC | 20 | 47 | 14 | 17000 | 22000 | 14.5 | 8.4 | 0.112 | ||
