Send Inquiry | Model | Overall dimension (mm) | Limit speed (RPM) | Rated load/th> | Weight | ||||
|---|---|---|---|---|---|---|---|---|---|---|
| d | D | B | Grease | Oil lubrication | Cr(N) | Cor(N) | ||||
| 30202 | 15 | 35 | 11 | 12000 | 16000 | 14.9 | 13.4 | 0.053 | ||
| 30244 | 220 | 400 | 73 | — | — | — | — | 35.5 | ||
| 30340 | 200 | 420 | 80 | 820 | 1100 | 1120 | 1450 | 53.5 | ||
| 30352 | 260 | 540 | 114 | — | — | — | — | 108 | ||
| 32205 | 25 | 52 | 19.25 | — | — | — | — | 0.174 | ||
| 32004 | 20 | 42 | 15 | 8500 | 11000 | 25 | 28.2 | 0.095 | ||
| 33205 | 25 | 52 | 22 | 7000 | 9000 | 47 | 55.8 | 0.216 | ||
| 30305 | 25 | 62 | 17 | 6300 | 8000 | 46.8 | 48 | 0.263 | ||
| 30204 | 20 | 47 | 14 | 8000 | 10000 | 28.2 | 30.5 | 0.126 | ||
| 31305 | 25 | 62 | 17 | 6300 | 8000 | 40.5 | 46 | 0.262 | ||
| 30304 | 20 | 52 | 15 | 8300 | 11000 | 30.5 | 28.4 | 0.17 | ||
| 32305 | 25 | 62 | 24 | 6300 | 8000 | 61.5 | 68.8 | 0.368 | ||
| 32304 | 20 | 52 | 21 | 7500 | 9500 | 42.8 | 46.2 | 0.23 | ||
| 329/28 | 28 | 45 | 12 | 750D | 9500 | 16.8 | 22.8 | 0.069 | ||
| 329/22 | 22 | 40 | 12 | 8500 | 11000 | 15 | 20 | 0.065 | ||
| 30302 | 15 | 42 | 13 | 9000 | 12000 | 22.8 | 21.5 | 0.094 | ||
| 320/28 | 28 | 52 | 16 | 6700 | 8500 | 31.5 | 40.5 | 0.142 | ||
| 320/22 | 22 | 44 | 15 | 8000 | 10000 | 26 | 30.2 | 0.1 | ||
| 30203 | 17 | 40 | 12 | 9000 | 12000 | 20.8 | 21.8 | 0.079 | ||
| 332/28 | 28 | 58 | 24 | 6300 | 8000 | 58 | 68.2 | 0.286 | ||
